$1.2-4.5/square meter
Description
Material :low carbon steel sheet ,galvanized sheet ,stainless steel plate
Thickness:3mm
Hole :12*30mm
Strand:4mm
Width:1000mm,1200mm,1250mm,1500mm
Length:2000mm,2400mm,2500mm,3000mm.
Packing :metal pallet or wooden case
plate thickness(mm) | hole width(mm) | hole length(mm) | mesh | mesh width(m) | mesh | weight(kg/m2) |
0.5 | 2.5 | 4.5 | 0.5 | 0.5 | 1 | 1.8 |
0.5 | 10 | 25 | 0.5 | 0.6 | 2 | 0.73 |
0.6 | 10 | 25 | 1 | 0.6 | 2 | 1 |
0.8 | 10 | 25 | 1 | 0.6 | 2 | 1.25 |
1 | 10 | 25 | 1.1 | 0.6 | 2 | 1.77 |
1 | 15 | 40 | 1.5 | 2 | 4 | 1.85 |
1.2 | 10 | 25 | 1.1 | 2 | 4 | 2.21 |
1.2 | 15 | 40 | 1.5 | 2 | 4 | 2.3 |
1.5 | 15 | 40 | 1.5 | 1.8 | 4 | 2.77 |
1.5 | 23 | 60 | 2.6 | 2 | 3.6 | 2.77 |
2 | 18 | 50 | 2.1 | 2 | 4 | 3.69 |
2 | 22 | 60 | 2.6 | 2 | 4 | 3.69 |
3 | 40 | 80 | 3.8 | 2 | 4 | 5.00 |
4 | 50 | 100 | 4 | 2 | 2 | 11.15 |
4.5 | 50 | 100 | 5 | 2 | 2.7 | 11.15 |
5 | 50 | 100 | 5 | 1.4 | 2.6 | 12.39 |
6 | 50 | 100 | 6 | 2 | 2.5 | 17.35 |
8 | 50 | 100 | 8 | 2 | 2.1 | 28.26 |
Application:
Mainly used in building cement, mechanical equipment protection etc.
1) Used as decorative mesh for building outer wall
2) Visibility and colorful
Packing:
Water-proofed paper,plastic film
FAQ:
Q.How to make a inquiry ?
A.You need to provide material, mesh number, wire diameter, size and the quantity to ask an offer, you can also indicate if you have any special requirement. We'll provide a formal quotation list after receiving your inquiry
Q: Are you trading company or manufacturer ?
A: We are factory.
