Price:US $0.8 - 3 / Square Meter
GALFAN, that is Zinc-aluminium alloy coating.
1.Gabion materials: hot dipped galvanized wire and PVC coated galvanized wire , Galfan coated wire
2.Gabion mesh wire:2.0mm,2.2mm,2.7mm,3.0mm,
3.Gabion selvage wire :2.4mm,2.7mm,3.4mm,3.9mm
4.Gabion mesh size : 6*8cm, 8*10cm, 10*12cm, 12*15cm
5.Gabion lacing wire : 2.2mm, 5% of gabion weight
6.Gabion Zinc coating : 245g/m2
7.Gabion size : 2X1X1m, 3X1X1m
8. Gabion Steel according to EN 10218-2 ,Tensile strength between 380N/mm2 and 500N/mm2
| Gabion box | |||
| Mesh Opening (MM) | Iron Wire Diameter (MM) | (PVC Wire)/ Inside diameter/Outer diameter(MM) | |
| 60X80 | 2.0-2.8 | 2.0/3.0-2.5/3.5 | |
| 80X100 | 2.0-3.2 | 2.0/3.0-2.8/3.8 | |
| 80X120 | 2.0-3.2 | 2.0/3.0-2.8/3.8 | |
| 100X120 | 2.0-3.4 | 2.0/3.0-2.8/3.8 | |
| 100X150 | 2.0-3.4 | 2.0/3.0-2.8/3.8 | |
| 120X150 | 2.0-4.0 | 2.0/3.0-3.0/4.0 | |
Features:
1. Economic.
2.Simple installation. No special technology needed.
3.corrosion resistant.
4.Good permeation
5.Less transport freight. It can be folded together for transport and further installation
Application:
Gabion basket applications:
Control and guide of water or flood
Flood bank or guiding bank
Preventing of rock breaking
Water and soil protection
Bridge protection
Strengthening structure of soil
Protection engineering of seaside area
FAQ:
Q: What kind of quality control do you have?
A: All goods have go though 4 checks during the production process and have to pass strict inspection before they go out.
Q: Do you have a test before loading?
A: We will have a test before loading
Q:Can you produce according to the samples?
A: Of course, we can design drawings as your request.
Price:US $0.8 - 3 / Square Meter
GALFAN, that is Zinc-aluminium alloy coating.
1.Gabion materials: hot dipped galvanized wire and PVC coated galvanized wire , Galfan coated wire
2.Gabion mesh wire:2.0mm,2.2mm,2.7mm,3.0mm,
3.Gabion selvage wire :2.4mm,2.7mm,3.4mm,3.9mm
4.Gabion mesh size : 6*8cm, 8*10cm, 10*12cm, 12*15cm
5.Gabion lacing wire : 2.2mm, 5% of gabion weight
6.Gabion Zinc coating : 245g/m2
7.Gabion size : 2X1X1m, 3X1X1m
8. Gabion Steel according to EN 10218-2 ,Tensile strength between 380N/mm2 and 500N/mm2
| Gabion box | |||
| Mesh Opening (MM) | Iron Wire Diameter (MM) | (PVC Wire)/ Inside diameter/Outer diameter(MM) | |
| 60X80 | 2.0-2.8 | 2.0/3.0-2.5/3.5 | |
| 80X100 | 2.0-3.2 | 2.0/3.0-2.8/3.8 | |
| 80X120 | 2.0-3.2 | 2.0/3.0-2.8/3.8 | |
| 100X120 | 2.0-3.4 | 2.0/3.0-2.8/3.8 | |
| 100X150 | 2.0-3.4 | 2.0/3.0-2.8/3.8 | |
| 120X150 | 2.0-4.0 | 2.0/3.0-3.0/4.0 | |
Features:
1. Economic.
2.Simple installation. No special technology needed.
3.corrosion resistant.
4.Good permeation
5.Less transport freight. It can be folded together for transport and further installation
Application:
Gabion basket applications:
Control and guide of water or flood
Flood bank or guiding bank
Preventing of rock breaking
Water and soil protection
Bridge protection
Strengthening structure of soil
Protection engineering of seaside area
FAQ:
Q: What kind of quality control do you have?
A: All goods have go though 4 checks during the production process and have to pass strict inspection before they go out.
Q: Do you have a test before loading?
A: We will have a test before loading
Q:Can you produce according to the samples?
A: Of course, we can design drawings as your request.
